Large wheel for better obstacle-crossing ability
Low energy consumption, the total transmission efficiency of the direct motor drive systems reaches 95%, more than 30% energy saving compared with the traditional hydraulic system.
Safer, higher levels of water and dust resistance, with built-in position sensors, real-time data monitoring of the full stroke. Synergistic drives enable temperature, load, and variable torque control, offering high active safety.
Easy maintenance, no hydraulic system, avoid system problems such as valve core stuck, oil leakage, oil change, high and low temperature efficiency reduction, equipped with maintenance-free permanent magnet synchronous motor and AGM battery, which greatly reduces maintenance costs.
More comfortable, full stroke proportional control eliminates the jitter and abrupt feeling caused by self-gravity lowering of the hydraulic system, providing a better experience.
More environmentally friendly, the noise of the machine is lower than that with the hydraulic system, all-electric and oil-free, zero-emission, high degree of environmental protection.
Max. Working Height: 7.60m/24ft 11in
Max. Platform Height: 5.60m/18ft 4in
Overall Length(With Ladder): 1.54m/5ft 1in
Overall Height(Rails Up): 0.81m/2ft 8in
Overall Height(Rails Down): 2.09m/6ft 10in
Platform Size(Length×Width): 1.73m/5ft 8in
Platform Extension Size: 1.37m×0.70m/4ft 6in×2ft 4in
Ground Clearance(Stowed/Raised): 0.60m/2ft
S.W.L On Extension: 230kg/507lb
Max. Occupants: 113kg/249lb
Gradeability: 2
Overall Weight(Lithium Battery): 1340kg/2954lb
Charger: 24V/115Ah
