No hydraulic system, electric actuators are used for lifting, lowering and steering instead of traditional hydraulic oil cylinders.
Low energy consumption, the total transmission efficiency of the direct motor drive systems reaches 95%, more than 30% energy saving compared with the traditional hydraulic system, realizing long endurance.
Safer, higher levels of water and dust resistance, with built-in position sensors, real-time data monitoring of the full stroke. Synergistic drives enable temperature, load, and variable torque control, offering high active safety.
Easy maintenance, no hydraulic system, avoid troubles such as valve core stuck, oil leakage, oil change, high and low temperature efficiency reduction, equipped with maintenance-free permanent magnet synchronous motor and AGM battery, which greatly reduces maintenance costs.
More comfortable, full stroke proportional control eliminates the jitter and abrupt feeling caused by self-gravity lowering of the hydraulic system, providing a better experience.
More environmentally friendly, the noise of the machine is lower than that with the hydraulic system, all-electric and oil-free, zero-emission, high degree of environmental protection.
Max. Working Height: 8.00m/26ft 3in
Max. Platform Height: 6.00m/19ft 8in
Overall Length(With Ladder): 2.48m/8ft 2in
Overall Width: 0.83m/2ft 9in
Overall Height(Rails Up): 2.28m/7ft 6in
Overall Height(Rails Down): 1.92m/6ft 4in
Platform Size(Length×Width): 2.27m×0.81m/7ft 5in×2ft 8in
Platform Extension Size: 0.90m/2ft 11in
S.W.L: 380kg/837lb
S.W.L On Extension: 113kg/249lb
Max. Occupants: 2/1
Overall Weight(Lead-acid Battery): 2290kg/5048lb
Battery: 24V/185Ah
Charger: 24V/30A
