Enhanced operator comfort—spacious cab, intuitive single joystick and integrated arm rest
Maximum serviceability— extended service intervals, easy-to-access parts and durable components for less overall maintenance
Greater operator confidence— better visibility, Stabil-Trak rear axle stabilization, precision gravity lowering system, optional reverse sensing system and reversing camera
Increased versatility—wide range of attachment options
Standard LED Motion/Amber Beacon with ClearSky Smart Fleet Connectivity Hardware
Maximum Lift Capacity: 10000 lb / 4535.92 kg
Outriggers Up Max Lift Height: 55 ft / 16.76 m
Maximum Lift Height: 55 ft / 16.76 m
Maximum Reach: 42 ft / 12.8 m
| Performance | |
| Drawbar Pull | 25400 lb / 11521.25 kg |
| Frame Leveling | 10 Degrees |
| Load Center | 2 ft / 0.61 m |
| Maximum Lift Capacity | 10000 lb / 4535.92 kg |
| Outriggers Up Max Lift Height | 55 ft / 16.76 m |
| Outriggers Up Max Forward Reach | 42 ft / 12.8 m |
| Lift Capacity at Full Height | 5000 lb / 2267.96 kg |
| Lift Capacity at Max Reach | 3000 lb / 1360.78 kg |
| Maximum Reach | 42 ft / 12.8 m |
| Maximum Lift Height | 55 ft / 16.76 m |
| Outriggers or Stabilizers | Yes |
| Outside Turning Radius | 14 ft / 4.27 m |
| Speed - Maximum Lift | 14 sec. |
| Speed - Maximum Lower | 11 sec. |
| Speed - Maximum Telescope In | 15 sec. |
| Speed - Maximum Telescope Out | 16 sec. |
| Speed - Maximum Travel | 20 mph / 32.19 km/h |
| Dimensional Data | |
| Ground Clearance | 1 ft 6 in. / 0.46 m |
| Machine Height | 8 ft 4 in. / 2.54 m |
| Machine Length | 20 ft 1 in. / 6.12 m |
| Machine Width | 8 ft 5 in. / 2.56 m |
| Tire Size | 400/75-28 |
| Wheelbase | 11 ft 6 in. / 3.49 m |
