Maximum work height10.08 m
Safety working load12065.56 kg
Greater Capacity – 26,600-lb capacity to tackle heavy pick-and-carry applications.
Lower Project Costs – Delay or eliminate the need for wheel loaders in certain applications where greater lift height and forward reach is required.
Best-in-Class Cab – Superior cab comfort with excellent visibility, intuitive single joystick control and wrap-around dash.
Maximum Lift Capacity: 26600 lb / 12065.56 kg
Maximum Lift Height: 33 ft 1 in. / 10.08 m
Maximum Reach: 17 ft 7 in. / 5.36 m
Performance | |
Drawbar Pull | 28500 lb / 12927.38 kg |
Frame Leveling | 8 Degrees |
Lift Capacity at Full Height | 15500 lb / 7030.68 kg |
Lift Capacity at Max Reach | 8000 lb / 3628.74 kg |
Maximum Lift Capacity | 26600 lb / 12065.56 kg |
Maximum Lift Height | 33 ft 1 in. / 10.08 m |
Maximum Reach | 17 ft 7 in. / 5.36 m |
Outriggers or Stabilizers | No |
Outside Turning Radius | 14 ft 8 in. / 4.47 m |
Speed - Maximum Lift | 16 sec. |
Speed - Maximum Lower | 11 sec. |
Speed - Maximum Telescope In | 14 sec. |
Speed - Maximum Telescope Out | 12 sec. |
Speed - Maximum Travel | 17 mph / 27.36 km/h |
Dimensional Data | |
Ground Clearance | 1 ft 5 in. / 0.43 m |
Machine Height | 10 ft / 3.05 m |
Machine Length | 20 ft 9 in. / 6.32 m |
Machine Width | 8 ft 2 in. / 2.49 m |
Tire Size | 17.5-25 Air CAMSO L2 |
Wheelbase | 11 ft 10 in. / 3.61 m |
