Hydrostatic transmission for ease of operation.
Advanced control system that allows for more options and provides improved diagnostics.
Lightweight design that allows for efficient transport.
Electric over hydraulic joystick for greater multifunction capability.
Standard LED Motion/Amber Beacon with ClearSky Smart Fleet Connectivity Hardware.
Maximum Lift Capacity: 8000 lb / 3628.74 kg
Maximum Lift Height: 42 ft 4 in. / 12.9 m
Maximum Reach: 29 ft 6 in. / 8.99 m
| Performance | |
| Drawbar Pull | 15062 lb / 6832.01 kg |
| Frame Leveling | 10 Degrees |
| Lift Capacity at Full Height | 6000 lb / 2721.55 kg |
| Lift Capacity at Max Reach | 1600 lb / 725.75 kg |
| Load Center | 2 ft / 0.61 m |
| Maximum Lift Capacity | 8000 lb / 3628.74 kg |
| Maximum Lift Height | 42 ft 4 in. / 12.9 m |
| Maximum Reach | 29 ft 6 in. / 8.99 m |
| Outriggers or Stabilizers | No |
| Outside Turning Radius | 12 ft 10 in. / 3.91 m |
| Speed - Maximum Lift | 15.5 sec. |
| Speed - Maximum Lower | 12.3 sec. |
| Speed - Maximum Telescope In | 12 sec. |
| Speed - Maximum Telescope Out | 14.6 sec. |
| Speed - Maximum Travel | 15 mph / 24.14 km/h |
| Dimensional Data | |
| Ground Clearance | 1 ft 6 in. / 0.46 m |
| Machine Height | 8 ft 6 in. / 2.59 m |
| Machine Width | 8 ft 4 in. / 2.53 m |
| Tire Size | 370/75-28 |
| Wheelbase | 10 ft 2 in. / 3.1 m |
| Machine Length | 19 ft 11 in. / 6.07 m |
