R11100 ROTATING MODEL

R11100 ROTATING MODEL

Maximum work height29.57 m

Safety working load4989.52 kg

Overview

Specifications

Related Products

Leave Message

Key Features

  • 3-in-1 Capability: Along with material handling, rotating telehandlers function as mobile elevating work platforms and rough-terrain cranes. 

  • Confidence-Inspiring Technology: Features automatic attachment recognition, a Load Management Information System (LMIS) and Load Stability Indicator (LSI). 

  • 360-Degree Continuous Rotation: Full rotation of the upper frame allows for both horizontal and vertical lifting. 

  • Highest-Reaching JLG Telehandler: 97-ft lift height.


Specifications

Key Specs

  • Maximum Lift Capacity: 11000 lb / 4989.52 kg

  • Outriggers Up Max Lift Height: 72 ft / 21.95 m

  • Maximum Lift Height: 97 ft / 29.57 m

  • Maximum Reach: 86 ft / 26.21 m

Performance
Drawbar Pull22500 lb / 10205.83 kg
Frame Leveling6 Degrees
Outriggers Up Lift Capacity Full Height3300 lb / 1496.85 kg
Outriggers Up Lift Capacity Full Reach700 lb / 317.51 kg
Load Center2 ft / 0.61 m
Maximum Lift Capacity11000 lb / 4989.52 kg
Outriggers Up Max Lift Height72 ft / 21.95 m
Outriggers Up Max Forward Reach47 ft 6 in. / 14.48 m
Lift Capacity at Full Height4400 lb / 1995.81 kg
Lift Capacity at Max Reach300 lb / 136.08 kg
Maximum Reach86 ft / 26.21 m
Outriggers Down Max Lift Capacity11000 lb / 4989.52 kg
Maximum Lift Height97 ft / 29.57 m
Outriggers or StabilizersYes
Outside Turning Radius14 ft 6 in. / 4.42 m
Speed - Maximum Lift14.5 sec.
Speed - Maximum Lower9.5 sec.
Speed - Maximum Telescope In14 sec.
Speed - Maximum Telescope Out29 sec.
Speed - Maximum Travel12.4 mph / 19.96 km/h
Dimensional Data
Ground Clearance1 ft 3 in. / 0.38 m
Machine Height10 ft 1 in. / 3.07 m
Machine Length27 ft 6 in. / 8.38 m
Machine Width8 ft 2 in. / 2.49 m
Tire Size18 x 22.5
Wheelbase10 ft 8 in. / 3.25 m
